Product Overview
The Analytik Jena qTOWER³ product family includes configurable 96-well and 384-well real-time PCR thermal cyclers for research applications. The systems combine precise block temperature control with a fiber-optic shuttle, four-color LED light source and interchangeable filter modules for fluorescence detection.
Each qTOWER³ configuration accommodates up to six optical modules selected from 12 available color, FRET and protein modules. The system supports up to six-fold multiplexing and reads a complete 96- or 384-well plate in approximately six seconds, regardless of the number of installed filter modules.
The family includes PC-controlled, gradient and touchscreen configurations. The 96-well systems use a gold-coated silver block, while the qTOWER³ 84 systems extend the platform to a 384-well aluminum block for higher-throughput research workflows. These products are for research use only. Contact Jant Pharmacal to confirm current model availability, optical configuration, included components and support options.
96- or 384-Well Formats
Choose a 96-well 0.2 mL platform or a 384-well configuration for higher-throughput qPCR research.
Up to Six-Fold Multiplexing
Six optical positions accept a configurable selection from 12 available color, FRET and protein modules.
Six-Second Plate Readout
The fiber-optic shuttle reads a complete plate in approximately six seconds, independent of the number of filters used.
Key Features
- Real-time PCR amplification and fluorescence detection for DNA or RNA research workflows
- Available in 96-well and 384-well formats
- Up to six optical modules and six-fold multiplexing
- Configurable color, FRET and protein modules that can be exchanged or expanded
- Four long-life, high-performance RGBW LEDs
- Highly sensitive photomultiplier tube detector
- Six-second readout for a complete 96- or 384-well plate
- 96-well systems provide heating rates up to 8°C/s and cooling rates up to 6°C/s
- Gradient models support the Analytik Jena Linear Gradient Tool
- Motorized heated lid adjustable from 30°C to 110°C
- qPCRsoft software for instrument control and data analysis
- Touch models include an integrated 10-inch display for standalone operation
- Open research platform supporting compatible plates, strips, dyes, probes and master mixes
Designed for Flexible qPCR Research
Configurable Optics
The fiber-optic shuttle excites and detects each well individually. Up to six modules can be configured for common dyes, FRET probe combinations or protein-binding applications.
Precise Thermal Cycling
The 96-well systems use a gold-coated silver block, with temperature control precision of ±0.1°C and uniformity of 55°C ±0.15°C after 15 seconds.
Integrated Analysis
qPCRsoft supports absolute and relative quantification, the ΔΔCt method, PCR efficiency, allelic discrimination, endpoint analysis, melting curves and multiplate analysis.
Compare qTOWER³ Models
Select the block capacity, gradient capability and control format appropriate for the laboratory’s workflow. Current availability must be confirmed with Jant Pharmacal.
| Model | Jant Catalog Number | Block Capacity | Control | Gradient |
|---|---|---|---|---|
| qTOWER³ | AJ844-00503-2 | 96 wells, 0.2 mL format | PC with qPCRsoft | No |
| qTOWER³ G | AJ844-00504-2 | 96 wells, 0.2 mL format | PC with qPCRsoft | Up to 40°C across 12 columns |
| qTOWER³ touch | AJ844-00505-2 | 96 wells, 0.2 mL format | Integrated 10-inch touchscreen and PC software | No |
| qTOWER³ G touch | AJ844-00506-2 | 96 wells, 0.2 mL format | Integrated 10-inch touchscreen and PC software | Up to 40°C across 12 columns |
| qTOWER³ 84 | AJ844-00508-2 | 384 wells | PC with qPCRsoft | No |
| qTOWER³ 84 G | AJ844-00509-2 | 384 wells | PC with qPCRsoft | Up to 24°C across 24 columns |
Technical Specifications
| Specification | qTOWER³ / qTOWER³ touch | qTOWER³ 84 |
|---|---|---|
| Research Application | Real-time PCR detection and quantification of DNA or RNA targets | |
| Thermal Block | Gold-coated silver block | Special-alloy aluminum block |
| Block Capacity | 96 wells in 0.2 mL format | 384 wells |
| Reaction Volume | 5–80 µL | 2–30 µL; 5–20 µL recommended in the brochure |
| Maximum Heating Rate | 8°C/s | 4°C/s |
| Maximum Cooling Rate | 6°C/s | 2°C/s |
| Temperature Setting Range | 4–99°C | |
| Temperature Control Precision | ±0.1°C | |
| Temperature Uniformity | 55°C ±0.15°C after 15 seconds | |
| Gradient Models | qTOWER³ G and qTOWER³ G touch: 0.1–40°C range across 12 columns | qTOWER³ 84 G: 0.1–24°C range across 24 columns |
| Heated Lid | 30–110°C; automated 30 kg contact pressure | |
| Optical Scanner | Fiber-optic shuttle with eight scanning fibers | Fiber-optic shuttle with 16 scanning fibers |
| Light Source | Four long-life, high-performance RGBW LEDs | |
| Detector | Photomultiplier tube (PMT) | |
| Optical Modules | 12 available color, FRET and protein modules; six positions in the instrument | |
| Plate Readout Time | Approximately six seconds, regardless of the number of filters | |
| Control Software | qPCRsoft; PC-controlled models or 10-inch integrated touchscreen on touch configurations | |
| PC Interface | USB | |
| Dimensions | 275 mm W × 585 mm H × 275 mm D (approximately 10.8 × 23.0 × 10.8 inches) | |
| Weight | Approximately 30 kg (66 lb) | |
| Noise Emission | 45 dB | |
| Use Classification | For research use only | |
Specifications are based on the Jant-hosted Analytik Jena qTOWER³ Product Family brochure. Configuration, software, included modules, warranty, service coverage and availability may change. Confirm the quoted system and current manufacturer documentation before purchase.
Optical Modules, Reagents and Consumables
The qTOWER³ is a configurable research platform. The final setup depends on the fluorophores, multiplexing requirements, reaction format and control method used by the laboratory. Confirm compatibility and current availability before ordering any system component.
Configurable Optical Modules
- Color modules for commonly used qPCR fluorophores
- FRET modules for compatible donor/acceptor probe combinations
- Protein module for compatible protein-binding dyes
- Up to six modules installed in the instrument
Workflow Materials
- Compatible qPCR master mixes and assay reagents
- 96-well or 384-well PCR plates appropriate for the selected model
- Optical tube strips, caps and sealing films
- Extraction and sample-preparation products appropriate for the application
Explore Jant Real-Time PCR Resources
Explore Jant Pharmacal’s real-time PCR analyzers, standard multiplex panels and custom pre-plated panel options for research workflows.
Explore Real-Time PCR View Standard Multiplex Panels View Custom Pre-Plated PanelsJant molecular products are identified on the website as research-use products unless a product page and its current labeling expressly state otherwise. A category link does not establish compatibility with a particular qTOWER³ configuration. Confirm optical channels, cycling parameters, consumables, software requirements and validation needs before implementing an assay.
Important Product Information
- The qTOWER³ systems described on this page are for research use only and are not presented as in vitro diagnostic devices.
- Gradient capability is limited to models with “G” in the model name.
- Only qTOWER³ touch and qTOWER³ G touch include the integrated 10-inch touchscreen described in the brochure.
- The 96-well and 384-well models have different block materials, reaction-volume ranges and heating/cooling rates.
- The selected optical modules must match the fluorophores and probe chemistry used in the laboratory’s assay.
- The brochure describes a 10-year long-term warranty for the high-performance optical components. Current warranty terms and exclusions must be confirmed in the Jant quotation.
- Model availability, included optical modules, software, computer requirements, installation, training and service coverage must be confirmed before ordering.
Documentation and Resources
Review the qTOWER³ product-family brochure for complete model comparisons, optical-module wavelengths, example fluorophores, compatible consumables and technical specifications.
qTOWER³ Product Family Brochure Watch the qTOWER³ Product VideoFrequently Asked Questions
The qTOWER³ family consists of configurable real-time PCR thermal cyclers for DNA or RNA research workflows. The family includes 96-well and 384-well instruments, gradient options and 96-well touchscreen configurations.
No. The qTOWER³ systems on this Jant page are presented for research use only. They are not presented as in vitro diagnostic devices, and diagnostic claims should not be made for these configurations.
The qTOWER³ and qTOWER³ touch systems use a 96-well, 0.2 mL gold-coated silver block. The qTOWER³ 84 systems use a 384-well aluminum block for higher-throughput workflows. Reaction volumes and maximum ramp rates also differ between the formats.
The qTOWER³ G and qTOWER³ G touch provide a gradient range of up to 40°C across 12 columns. The qTOWER³ 84 G provides a gradient range of up to 24°C across 24 columns. Models without “G” do not include the gradient feature shown in the brochure.
The 96-well qTOWER³ touch and qTOWER³ G touch include an integrated 10-inch touchscreen for standalone operation and also include the PC qPCRsoft package. The other listed configurations are PC-controlled.
The system accommodates up to six optical modules and supports up to six-fold multiplexing when the instrument configuration, fluorophores, assay design and analysis method are compatible.
The brochure lists a readout time of approximately six seconds for a complete 96-well or 384-well plate, regardless of the number of installed filters.
The brochure lists absolute and relative quantification, the ΔΔCt method, PCR-efficiency analysis, allelic discrimination, endpoint detection, melting-curve analysis, protein analysis and multiplate analysis. Available functions can depend on the software version and system configuration.
Compatibility must be evaluated for the specific instrument, optical modules, fluorophores, cycling protocol, plate format and panel. A link to Jant’s real-time PCR category does not by itself establish compatibility. Confirm requirements with Jant and follow the applicable research-use documentation.
Availability may vary by model and configuration. Contact Jant Pharmacal to confirm whether the requested system, optical modules, software and accessories are currently available or whether a newer platform should be considered.
Identify the required plate format, gradient capability, touchscreen preference, fluorophores, number of optical channels, reaction volume, analysis methods and expected throughput. Jant can then confirm the appropriate configuration, included components, warranty, installation, training and support.
Ordering Information
To confirm current availability, configure a system or request a quote, call Jant Pharmacal at 800.676.5565
| Catalog Number | Description | Block Capacity | Unit of Measurement |
|---|---|---|---|
| AJ844-00503-2 | qTOWER³ | 96 wells, 0.2 mL | Each |
| AJ844-00504-2 | qTOWER³ G | 96 wells, 0.2 mL | Each |
| AJ844-00505-2 | qTOWER³ touch | 96 wells, 0.2 mL | Each |
| AJ844-00506-2 | qTOWER³ G touch | 96 wells, 0.2 mL | Each |
| AJ844-00508-2 | qTOWER³ 84 | 384 wells | Each |
| AJ844-00509-2 | qTOWER³ 84 G | 384 wells | Each |
Confirm model availability, installed optical modules, software, included computer or touchscreen, accessories, installation, training, warranty and service coverage when requesting a quote.
